Model |
Airflow |
Voltage/Hz |
Power |
Wind Pressure |
N.W. |
Applicable Area |
Air Delivery(pipeline) |
Air Outlet
|
XK-20S-UP |
20000 m3/h |
380/50Hz |
1.5Kw |
250Pa |
110Kgs |
150-200m2 |
30-35m |
422*452mm |
220/50Hz |
XK-20S-DOWN |
20000 m3/h |
380/50Hz |
1.5Kw |
250Pa |
108Kgs |
150-200m2 |
30-35m |
422*452mm |
220/50Hz |
XK-20S-SIDE |
20000 m3/h |
380/50Hz |
1.5Kw |
250Pa |
110Kgs |
150-200m2 |
30-35m |
422*452mm |

Air cooler components:
- Water distribution system
- 100mm thickness 5090# cooling pad
- Centrifugal Fan
- Cast iron motor body
- Control System
- Water pump and drain pump
- Body case
Cooling Ability:

1. Water distribution system. PVC water pipe. Open water diversion plate, not easy to jam. Anti-corrosion. Water supply evenly. Long working life.

2. 100mm thickness 5090# cooling pads. Raw material from Jia Mu Si, deodorant treatment, more than 80% evaporate rate. Perfect edge protection, 3 years warranty.

3. Centrifugal fan. Direct-coupled centrifugal fan, Zinc coating centrifugal fan and volute. Anti-rust, anti-Corrosion, stable operation and low noise.

4. Cast iron motor body. 8P motor with cast iron motor body. Motor Bearing Import from Japan, 100% copper-wire motor winding. Water-proof Rate IP 54, INS Class B. Long working life time, 2 years warranty.

5. Control system. Flame-retardant PCB control box. Damp proof, fast heat dissipation. LCD display with remote controller. All kinds of protection function. (380V: Printed circuit board, one wind speed.)

6. Water pump and drain pump. Ceramic shaft submersible pump. Barrier-free mechanical drain pump, corrosion resistance and efficient performance, 30000 hours continuously working life.

7. Body case. 100% New PP material, not recyclable, anti-UV, anti-corrosion, anti-aging, better heat-resistant performance: <60℃, 8 years warranty, more than 12 years lifetime.
